Controller to Controller / Converter
8-core shielded twisted wire diameter not less than 0.3 mm2
Card reader to controller
8-core shielded twisted wire , and diameters not less than 0.3 mm2 within 100m
Button to controller
Two core wire with a wire diameter of 0.3 square millimeters or ormore
Em Lock to controller
Two core power cable , wire diameter is more than 1.0 square millimeters . less than 50m
Door sensor to controller
Two core magnetic wire , wire diameters is more than 0.3 square millimeters , within 100m
Key Benefits
| 1 . Modular construction allows adaptation all kinds of intersections |
| 2 . One design for the whole city , independent of different functions of each intersection |
| 3 . No movable parts that can be manipulated |
| 4 . Resistant against vandalism due to a strong polycarbonate body with an integrated metal core profile |
| 5 . Laterally applied tactile symbols for describing the crossing for the visually impaired |
| 6 . Local is action of the push button due to acoustic and optical position signal ( led-ring ) . |
| 7 . Meets all the requirements of current guidelines and egulations ( Rails , DIN local regulations 32981 . DIN VDE 0832 ,EN 50293 |
